GM-D9701
₨20,350
1-Channel – Class D, 2400w Max Power – Mono Amplifier
- 2,400 Watts Max Power
- High Quality Textured Flat Panel and Tough Frame
- Bass Boost Remote Included
STANDARDS
-
Yes
PERFORMANCE
-
1 ohm to 8 ohm allowable
-
3.5 A x 1-Channel – 4 Ohm / 7.5 A x 1-Channel – 1 Ohm / 5.1 A x 1-Channel – 2 Ohm
-
50 Hz – Frequency
-
500 W x 1-Channel – 4 Ohm / 1200 W x 1-Channel – 1 Ohm / 800 W x 1-Channel – 2 Ohm
-
LPF – 40Hz-240Hz
-
-12 dB/oct
-
10 Hz to 240 Hz
-
10 Hz to 50 kHz (+0dB,-3dB) A/B Ch
-
40A x 3
-
1000 W x 1-Channel (4 Ohm) / 2400 W x 1-Channel (1 ohm)
-
200 mV to 6.5 V – RCA / 0.8 V to 16 V – Speaker
-
2-Channel
-
75 dBA (Reference: 1 W into 4 ohm)
-
Yes
-
=/< 1% ( 20 Hz to 240 Hz)
AMPLIFIER FEATURES
-
Yes
-
D
-
Negative
-
14.4V (10.8 V to 15.1 V allowable)
-
Yes
-
Block
-
6 lbs
-
